BPBlueprintAtlas · v1.0

§ Category / Index

Vehicles

How the world moves.

10 / 10 sheets

Revised 2026

Boeing 747

Sheet 001

Boeing 747

The original jumbo jet, with a distinctive upper-deck hump and four high-bypass turbofan engines. It democratised long-haul air travel for nearly half a century.

Length: 70.6 mWingspan: 64.4 mMTOW: 447 t
Ford Model T

Sheet 002

Ford Model T

The first affordable automobile, mass-produced on the moving assembly line pioneered by Henry Ford. It put the middle class on wheels and rewrote industrial manufacturing forever.

Power: 20 hpTop speed: 72 km/hUnits: 15 M
Steam Locomotive

Sheet 003

Steam Locomotive

A coal-fired reciprocating steam engine that converts fuel into mechanical work through a firebox, boiler, cylinders, and driving wheels — the motive power that built the industrial age.

Power: ~1,700 kWWeight: 96 tTop speed: 160 km/h
Bicycle

Sheet 004

Bicycle

The most energy-efficient form of transportation ever invented. The diamond frame, pneumatic tyre, and chain drive remain largely unchanged more than a century after their introduction.

Efficiency: >90%Weight: 7–15 kgGears: 1–30
Tesla Model S

Sheet 005

Tesla Model S

The full-size luxury electric sedan that proved EVs could be desirable, fast, and long-range. Its skateboard battery pack became the template for modern electric vehicles.

Range: 637 km0–100: 2.1 sBattery: 100 kWh
Space Shuttle

Sheet 006

Space Shuttle

The first partially-reusable crewed spacecraft. A delta-winged orbiter rode twin solid boosters and an external tank to orbit, then glided home unpowered for a runway landing.

Length: 37 mThermal tiles: 24,000Missions: 135
Container Ship

Sheet 007

Container Ship

The backbone of global trade. Roughly 90% of goods move by sea; the standardised intermodal container and the ships that carry them made modern supply chains possible.

Length: 400 mCapacity: 24,000 TEUCrew: 25
Saturn V Rocket

Sheet 008

Saturn V Rocket

The three-stage super heavy-lift rocket that carried astronauts to the Moon. Its five F-1 engines remain the most powerful single-chamber liquid-fuel engines ever flown.

Height: 110.6 mMass: 2,950 tThrust: 34.5 MN
Helicopter

Sheet 009

Helicopter

A rotorcraft whose lift and thrust come from powered rotors, enabling vertical takeoff, hover, and precise low-speed flight. The swashplate translates pilot input into cyclic blade pitch.

Rotor: ~14 mCruise: 260 km/hCeiling: ~6,000 m
Submarine

Sheet 010

Submarine

A stealthy underwater vessel propelled by a compact nuclear reactor. Its double-hull construction, ballast tanks, and anechoic tiles allow it to operate silently for months at a time.

Length: 170 mMax depth: >500 mCrew: ~130
